LK3240-P
LINKWELL
230V, 115V, DC 24V
0.48/0.46A, 0.26/0.24A, 0.58A
254x254x47mm
RAL 7035, color can be customized
IP 54, IP55, IP56
CE, Rohs
| Model No. fan-and-filter unit LK | 3240.230-LK | 3240.115-LK | 3240.024-LK |
| Model No. fan-and-filter unit EMC | 3240.230-EMC | 3240.115-EMC | 3240.024-EMC |
| Rated operating voltage, frequency V, Hz | 230V, 50/60Hz | 115V, 50/60Hz | 24V (DC) |
| Air throughput, unimpeded air flow | 240-220 m³/h | 220 m³/h | |
| Air throughput with the Exit filter, including the standard filter mat | 1 x LK 3240.300: 110-145 m³/h
2 x LK 3240.300: 155-185 m³/h 1 x LK 3240.300: 155-185 m³/h |
||
| Axial fan | Self-starting shaded pole motor | DC motor | |
| Rated current max. | 0.48-0.46 A | 0.26-0.24 A | 0.58 A |
| Rated Power | 41.0-38.0 W | 14 W | |
| Noise level | 48-50 dB(A) | 50 dB(A) | |
| Operating temperature range | -30 – +70°C | ||
| Model No. Exit filter LK / EMC | 3240.300 / 3240.300-EMC | ||
| Design | Made of injection-moulded thermoplastic, customizable flame retardant materials, consistent with UL94-VO self-extinguishing. | ||
