The humidistat MFR 012-2 is designed to control the heater in the switch box, which is
wet when the humidity exceeds 65%Gas will be expelled, and this method can
effectively prevent water droplets and rust.
The humidistat MFR 012-2 is designed to control the heater in the switch box, which is
wet when the humidity exceeds 65%Gas will be expelled, and this method can
effectively prevent water droplets and rust.
●Adjustable relative humidity
●Easy access
●Transition contact
●Rail clamp
●High conversion capacity
●Long service life
| Switching error | 4% relative humidity(±3% tolerance) |
| Relative humidity range | 35%~95% |
| Allowable wind speed | 15m/sec |
| Contactor type | Conversion contact |
| Contactor resistance | <10mΩ |
| Service life | >50000 cycles |
| Minimum switching capacity | 20VAC/DC 100mA |
| Maximum switching load | 250VAC,5(1)A,DC20W |
| Connection method | 3.pole wiring terminal,maximum clamping torque 0.5Nm:2.5mm2for steel wire, |
| 1.5mm2 for multi-stranded glued wire (end) | |
| Shell | UL94V-0 plastic,light gray, |
| Install | Installation of 35mm DIN rail |
| Size | 67x50x38mm |
| Weight | 60g |
| Fixed position | At will |
| Operating/storage temperature | 0~+60C(+32~+140°F)/-20~+80°C(-4~+176°F) |
| Protection level |
