Temperature range | 0~60℃ |
Switching Temperature Difference | 7k(+4k tolerance) |
Sensing Element | Electronic components |
Contactor Type | Switching contactor (relay) |
Contactor Resistance | <10m(with connecting wire) |
Service Life | >100000 cycles |
Maximum Switching Load | 250vac10(2)a120vac,15(2)a30w |
Connection Method | 4-pole terminal post,maximum clamping torque 0.5Nm:2.5mm2steel wire, |
multi-stranded glued wire (wired)1.5mm2 | |
Shell | UL94V-O plastic, light gray, |
Install | Installation of 35mm din rail |
Size | 72x58x32mm |
Weight | 65g |
Fixed Position | At will |
AdaptTo Temperature | -20~+80C |
Protection Level | IP20 |
Lcd Display | It can display the settemperature and the change of ambienttemperature in the cabinet at all times |
